Basket Type Strainer
Description & Features
Basket type strainer is essentially a screen installed to allow liquids to pass through, but not larger items, The larger items fall to the bottom or are held in a basket for later clean out. DAGO offers a wide range of strainers in types of Y Strainer. T strainers & Basket strainer etc. A Strainer is a type of sieve typically associated with separating liquids from Solids In general, a sieve separates wanted/desired elements from unwanted material using a tool such as a mesh, net or other filtration or distillation methods, but it is also used for classification of powders by particle size, or for size measurement as an analytical technique. Strainers arrest pipeline debts such as scale, rust, jointing compound and weld metal in pipelines, protecting equipment and processes, This turotial considers the range of strainer and filter types in use and how to size and select them for different applications.
● Structured in Basket type
● Body: cast or Forged body in carbon steel, stainless steel, or Duplex
● Stainless steel: SS304, SS316 Screen as standard
● Mesh: 40 mesh, 60 mesh, 80 mesh, 100 mesh, 200 mesh
● Sizes: DN15-DN600
● Body Styles: Flanged, welded or Threaded Ends
● Pressure class: ANSI Class 150 to CL2500, PN10 to PN420
● Threaded Drain plug Device
Specifications
|
Size Range |
Body Material |
|
1"-24" DN25-DN600 |
WPB, WCB, TP304, TP316, TP316L |
|
Pressure Rating |
Screen Material |
|
Class150 PN10-PN16 |
SS304, SS316, SS316L |
|
End Connection |
Seat Material |
|
Flange, Butt Welding |
/ |
|
Structure Style |
Stem Material |
|
Full Port |
/ |
|
Actuator Options |
Design Standard |
|
/ |
MFD |
|
Temperature Range |
Face to Face Standard |
|
-29℃~425℃ |
MFD |
|
Connection Standard |
Test Standard |
|
Flange Drilling: ASME B16.5 CL150, EN1092 Butt Weld: ASME B16.25, GB/T 12224 |
API598 |
|
Brand |
DAGO or OEM |
|
Test |
100% quantity tested before delivery |
|
Guarantee |
12 months from date of shipment or Negotiable |
|
MOQ |
1 Set |
|
Sample |
Available |
|
Color |
Customer required or manufacturer default |
|
Packing |
Plastic bag wrapped inside, seaworthy wooden case outside |
|
Certificate |
API6D, CE, TUV, ISO9001, ISO14001, ISO45001, Mill Test Certificate |
|
Country of Origin |
Zhejiang, China |
|
HS Code |
848180 (universal), 8481804090 (China) |
|
Port |
Shanghai or Ningbo |
|
Payment Terms |
T/T, L/C, Western Union |
