Pressure Balance Lubricated Plug Valve
Description & Features
Pressure Balance Lubricated Plug Valve is a fast-switching straight-through valve, which can be opened or closed by rotating the channel port on the valve plug and the channel port on the valve body mainly by rotating 90 degrees. Another important feature of this valve is that it is easy to adapt to the multi-channel structure, so that one valve can obtain two to four different flow channels. This Pressure Balance Lubricated Plug Valve is most suitable as a cut-off and switch-on medium and shunt application.
● Pressure Balance Lubricated Plug Valve can be used in large-scale chemical industry, has the characteristics of rapid opening and closing, lightness, and low fluid resistance.
● The product has reasonable structure, reliable sealing, excellent performance and beautiful appearance.
● It has structural of flip-clip balanceable pressure and light on/off operation.
● This valve is not restricted by the installation direction, and the flow direction of the medium can be arbitrary.
Specifications
Size Range | Body Material |
1/2"-14" DN15-DN350 | WCB, LCB, LCC, CF8M |
Pressure Rating | Plug Material |
Class150-Class900 PN16-PN150 | WCB+ENP, LCC+Nitriding, CF8M+Nitriding, LCB+Nitriding, CA15+Nitriding |
End Connection | Seat Material |
Flange (FF, RF, RJ), BW, SW | 410, 316 |
Structure Style | Stem Material |
Pressure Balance Type | F6a |
Actuator Options | Design Standard |
Lever, Worm gear, Pneumatic, Electric | API599, API 6D |
Temperature Range | Face to Face Standard |
-20℃~300℃ | ASME B16.10 |
Connection Standard | Test Standard |
Flange Drilling: ASME B16.5 Butt welding design: ASME B16.25 | API598, API6D |
Brand | DAGO or OEM |
Test | 100% quantity tested before delivery |
Guarantee | 12 months from date of shipment or Negotiable |
MOQ | 1 Set |
Sample | Available |
Color | Customer required or manufacturer default |
Packing | Plastic bag wrapped inside, seaworthy wooden case outside |
Certificate | API6D, CE, TUV, ISO9001, ISO14001, ISO45001, Mill Test Certificate |
Country of Origin | Zhejiang, China |
HS Code | 848180 (universal), 8481804090 (China) |
Port | Shanghai or Ningbo |
Payment Terms | T/T, L/C, Western Union |
